Film & Photography Lighting



Introduce you all of the parameters about color rendering and accuracy.

Click here to read YujiCapture White Paper.

CRI - Color Rendering Index - Ra 95-98, R9 > 90

CRI is a measure of how accurately a light source illuminates objects' true colors. Our LED lights have CRI values of up to 98, indicating that our LED lights are able to produce white light that approximates halogen or incandescent lighting and natural daylight.

Click here for more information about CRI.

Yuji LED CRI Values (Ra 98)

TLCI - Television Lighting Consistency Index -
TCLI > 95

The TLCI metric was developed as an alternative to address the shortcomings of the commonly used CRI when used with photography equipment. Because the way cameras interpret light is slightly different to how humans perceive it, the TLCI attempts to provide a more accurate prediction of color fidelity of a light source for broadcast use.

Click here for more information about TLCI.

Yuji LED TLCI Value: 99

TM-30-18 Metric - avg Rf/Rg > 95

TM-30 metric is defined by Illuminating Engineering Society (IES), providing quantified measurements on overall average properties and describing a method for evaluating light source color rendition.As a new metric which offers comprehensive evaluation on color quality of new light sources especially for the Solid-state Lighting (SSL), TM-30-18 is widely accepted by the lighting markets.

Click here for more information about TM-30.

Yuji LED TM-30-18 metric - avg Rf/Rg > 95

CRI uniformity & consistency

Overall light uniformity is very important, and even has higher priority than single LEDs. This is because LEDs are usually mounted on strips or PCBs. Therefore, it is particularly important to maintain LED stability of performance and CRI value consistency in the process of mass production. The uniformity of LEDs is shown on the diagram from randomly samples.

CRI distribution of Yuji LED samples

CCT accuracy - True tungsten & daylight

The CCT (Correlated Color Temperature) range is always an important indicator of light color judgement. In fact, LED manufacturers are not able to produce all LEDs at an accurate CCT, for example 5600K. In the process of mass production, the chromaticity coordinate of LEDs distributes near around, which is called “Bin”. In order to increase the CCT accuracy, large Bin is usually divided by several zones, labelled by “Bin Code”, for example, Yuji G01 LEDs have 4 bin codes. LEDs are separated by the bin code in one production and LEDs in one package have the same bin code to ensure a high color consistency.

The picture on the right shows Yuji LED bins from generation 1stto the 3rd. Every upgradation reduces the bin by 50% and thus the LEDs produced are more concentrated at a particular CCT on the black body line. With this improvement from G01 to G03, we are gradually getting rid of different bin codes within or among the batches of production and thus the color accuracy could be guaranteed all the time.

(G01 in Blue, G02 in Red, G03 in Green).

Yuji LED chromaticity bin

Flicker free

LED lights oftentimes exhibit invisible flicker - rapid fluctuations in brightness that occur many times per second. Because of its rapid speed, this "flicker" in an LED lamp may not be visible, but can have physiological and neurological effects on our bodies, such as eye strain, fatigue, headaches and difficulty in concentration.

Click here for the flicker-free test video

Video frame under flikering LEDs vs Yuji flikering-free LEDs

Lifespan > 54,000 hours

LM-80 is an industry standard that can help users evaluate lifespan of LED products. It refers to a method for measuring the lumen depreciation of solid-state lighting sources, such as LED packages, modules and arrays. Illuminating Engineering Society (IES) created a standard methodology that would allow customers to evaluate and compare the lumen maintenance of LED components.

Basically, the report is commonly used to evaluate the time of lumen depreciation from 100% to 70%, but data is measured lumen depreciation over 9000 hours and calculate how long it will take to 70%.

In Yuji’s report, the lifespan of LEDs under TM-21 standard L70 is >54,000 hours.

Click here to get Yuji LM-80 report.

Lumen maintenance of Yuji LED
High CRI LED Corn Bulb E27  for Studio Softbox
High CRI LED Corn Bulb E27  for Studio Softbox
from $46.00

YujiLights™ High CRI 95+ LED Corn Bulb E27 36W G02 3200K/5600K for Studio Softbox - Pack: 1pc/4pcs

FEATURES LED Qty: 252pcs YUJI-BC-2835 SMD LEDs Power Consumption: 36W Input Voltage: AC 85-265V Color Temperature: 3200K/5600K (standard studio ...

View full details
from $46.00
YUJILEDS® High CRI 95+ 2in1 Tunable MCPCB 100W LED Module
YUJILEDS® High CRI 95+ 2-in-1 Tunable MCPCB 100W LED Module - Pack: 2pcs
from $294.00

YUJILEDS® High CRI 95+ 2-in-1 Tunable MCPCB 100W LED Module - Pack: 2pcs

FEATURES Capability to achieve the function of splicing light panel(1x2, 1x4 or 2x2) by using 2-pin Wago connectors without welding Smoothly switc...

View full details
from $294.00
YUJILEDS® High CRI 95+ High Efficacy High Brightness 2835M LED Flexible Strip
YUJILEDS® High CRI 95+ High Efficacy High Brightness 2835M LED Flexible Strip
Save 20%
$99.50
$79.60

YUJILEDS® High CRI 95+ High Efficacy High Brightness 2835M LED Flexible Strip - 128 LEDs/m - Pack: 5m/reel

FEATURES Film grade LED strip with precise 5600K Daylight (±100K) High CRI Ra>95, R9>90 High efficacy up to 115lm/W Newly developed high eff...

View full details
$99.50
$79.60
Save 20%
Yuji CRI 95+ RGBWW 5-in-1 LED flexible strip
Yuji CRI 95+ RGBWW 5-in-1 LED flexible strip
$299.00

YUJILEDS® High CRI 95+ Full Gamut RGBWW 5-in-1 LED Flexible Strip for Film & Photography Lighting

FEATURES CCT tunable from 2700K to 6500K 10 mm width flexible PCB with adhesive backing 12V/24V constant voltage compatible 60 LEDs per meter ...

View full details
$299.00
Yuji CRI 98 LED flexible strip
Yuji CRI 98 LED flexible strip
$224.28

YUJILEDS® Full Spectrum CRI 98 LED Flexible Strip - BiColor - Tungsten to Daylight - for Film & Photography Lighting

FEATURES Full emission spectrum close to sunlight CCT tunable from 2700K to 6500K (3200K to 5600K) 10 mm width flexible PCB with adhesive backi...

View full details
$224.28
Yuji CRI 95+ LED flexible strip
Yuji CRI 95+ LED flexible strip
$89.50

YUJILEDS® High CRI 95+ LED Flexible Strip - Tungsten - for Film & Photography Lighting

FEATURES CRI typ.98, R9/R12>90. 10 mm width flexible PCB with adhesive backing 16.5W per meter (5W per foot) Comes in a 16.5-ft reel (5 meters)...

View full details
$89.50
Yuji CRI 95+ RGBW LED flexible strip
$189.00

YUJILEDS® High CRI 95+ RGBW 4-in-1 LED Flexible Strip for Film & Photography Lighting

FEATURES 12 mm width flexible PCB with adhesive backing Comes in a 16.5-ft reel (5 meters) 12V/24V constant voltage compatible 60 LEDs per meter (...

View full details
$189.00
Yuji CRI 95+ LED flexible strip
Yuji CRI 95+ LED flexible strip
$89.50

YUJILEDS® High CRI 95+ LED Flexible Strip - Daylight - for Film & Photography Lighting

FEATURES CRI typ.98, R9/R12>90. 10 mm width flexible PCB with adhesive backing 16.5W per meter (5W per foot) Comes in a 16.5-ft reel (5 meters)...

View full details
$89.50
Yuji CRI 95+ LED flexible strip
Yuji CRI 95+ LED flexible strip
$99.50

YUJILEDS® High CRI 95+ LED Flexible Strip - BiColor - Tungsten to Daylight - for Film & Photography Lighting

FEATURES CCT tunable from 2700K to 6500K (3200K to 5600K) 10 mm width flexible PCB with adhesive backing 16.5W per meter (5W per foot) 12V/24V...

View full details
$99.50
Yuji CRI 95+ multirow LED strip / flexible LED panel
Yuji CRI 95+ multirow LED strip / flexible LED panel
$102.00

YUJILEDS® High CRI 95+ LED Multirow Strip - BiColor - Tungsten to Daylight - for Film & Photography Lighting

FEATURES CCT tunable from 2700K to 6500K 300mm*100mm*0.55mm (L*W*H) PCB with adhesive backing 24V constant voltage  36*12=432 LEDs per pcs (up to ...

View full details
$102.00
Yuji CRI 98 LED flexible strip
Yuji CRI 98 LED flexible strip
$224.28

YUJILEDS® Full Spectrum CRI 98 LED Flexible Strip - Tungsten - for Film & Photography Lighting

FEATURES Full emission spectrum close to sunlight CRI typ.98, R9/R12>90. 10 mm width flexible PCB with adhesive backing 16.5W per meter (5W pe...

View full details
$224.28
